Product Introduction
DT series online wrapper is applied on flow line wrapping, widely used automated production line, improve wrapping efficiency ,labor cost saving .at present, this kind of products have been widely used in chemical industry,electronics,food and beverage ,paper making and other industries.
DT2000FZ-H, compact structure. Advanced slewing bearing device, the bearing effect is better, the service life is longer. Convenient clearance and maintenance. The unique film clamping device ensure better wrapping effect. More durable. The wrapped goods are good for transportation, avoid the spoilage of goods during storage.
Wrapping process
The goods are transported on the conveyor line and arrive at the wrapping machine station
The switch controls the machine to start, the film is automatically put on and off, and the upper and lower winding is automatic.
Product's parameter
Model | DT2000FZ-L, DT2000FZ-H, DT2000FZ-HCS |
Wrapping size | (800-1400)*(800-1200)mm |
Wrapping efficiency | 30-50pallets per hour |
Turntable speed | 0-15rpm, adjustable |
Turntable size | Diameter: 2000mm, height:500mm, roller conveyor |
Turntable load | 2000kg |
Film carriage | Stretch ratio 350%, adjustable |
Top platen | optional |
Control system | PLC |
Pneumatic system | 0.6-0.8Mpa, 250NL/min |
Weight | 900kg |
Dimension | 2820mm*1800mm*(2600-3200)mm |
Power | 3kw, 380V 50HZ |
Product's detail
1. Variable Wrapping Force System
Automatically adjusts wrap force according to the shape of the pallet.
Ensures that every part of the pallet is wrapped tightly.
Protects the corners of the loads, preventing corner concave.
2. Saving Film Consumption
Achieves up to 350% pre-stretch rate.
Maximizes the value of each meter of stretch film.
Ensures standard constant releasing of film.
Provides fixed-point wrapping and quantitative use of film.
3. Electric Top Platen (Optional)
Automatically senses cargo height.
Guarantees the stability of the goods.
Ensures safety in production and assembly line work, while keeping the goods uniform.
4. Slewing Bearing Turntable
5. Lifting Column
6. Operational Panel
Service Support
Whole Technological Design
Toncin determines reasonable plans and selections by conducting more systematic laboratory tests, semi-industrialization tests and theoretical analysis calculations and adopting appropriate methods in light of the actual problems faced by customers. And it determines specific parameters through laboratory tests and semi-industrial tests.
Project Construction
Toncin can provide customers with integrated project services for its perfect project management system and experienced high-quality team and can also provide customers with its best services in achieving the ultimate project goal by carrying out the management work on the project quality, schedule, safety, cost, procurement, information files, organization and coordination etc. according to customer’s contractual documents. Toncin contracts the design, procurement, construction and trials etc. for the entire process or some certain stages of the construction project according to the contract and takes full liability for the quality, safety, duration and cost etc. of the contracted project.
Response Time and After-sales Services
If any failure due to a defect has occurred during the warranty period, our company has given the following response and promise: to respond within 12 hours and rush to the domestic scene within 72 hours. With a rigorous and efficient service architecture, diverse and flexible service and response means, Toncin is capable of providing response service up to 7* 24 hours to ensure that users can get help at any time during the warranty period.
